Pulse electronic fence technical solution

The modernization of the world's security technology is to integrate video surveillance, perimeter alarms, access control systems, intrusion detection, access control, patrol systems, etc. with computer digital control systems to form a modern, versatile, all-weather Dynamic integrated security management system.

As the first line of defense for the security system, perimeter security is very important. It has been reconfirmed from the single alarm and developed into a deterrent block plus alarm. However, at present, the domestic technology and application level are far from the foreign countries, and the products used can only be alarmed and have no blocking function.

The X6 intelligent perimeter security blocking alarm system uses a unique BI-polar design. Each front-end fence has a live line, which makes the intruder have no chance to use it. It has been widely used in the perimeter security field in foreign countries. Deterrence before the event, blocking and alarming when the incident occurs, but also delay the invasion time of the outside world, with strong security and reliability. The system is essentially different from the AC grid. It uses high-voltage pulses (5000-10000V) and low energy (less than 5 joules), so it does not pose a life hazard to humans, while the flexible fence of the electronic fence is over the pole and Special alloy wire, which does not support the weight of the human body, can sense the invasion of intruders and send out alarm signals to ensure the safety and reliability of the system.

X6 electronic fence perimeter protection is a high security perimeter security concept and technology system widely used in developed countries.

Perfect European and American technical standards and global manufacturing engineering industry. The system is based on excitation pulses, conductive sub-fences and detection

Alarm, build an active security concept of "electric shock block is the main, alarm disposal is supplemented". In recent years, it has been gradually promoted in China.

Used in high security projects such as airports, power stations, military, factories, communities, etc., to obtain good protection and customers.

Evaluation.

The X6 electronic fence system is to set up a pulse electronic fence detector in the peripheral area of ​​the non-access channel of the base.

Form an electronic fence for prevention and management. The electronic fence system is the first line of defense and the most important line of defense.

Take responsibility for the safety and security of the base. When someone illegally climbs over the wall or destroys, the detector can immediately transmit the alert.

To the management center, the management center receives and processes the alarm signal, and displays it on the electronic map of the base that jumps out of the computer.

Out of the intruding area; at the same time, the external sound and light alarm starts to alarm; the security personnel notified by the central duty officer

Immediately rushed to the scene to deal with. After the central security personnel finish processing on site, the alarm status of the alarm host and detector

Carry out recovery. The on-site alarm can also alarm the alarm at the same time, reminding nearby employees to pay attention and assist the security personnel.

Combining the technical characteristics of security facilities, and considering the overall management of the base intelligent system, the design is built on the perimeter of the base.

A pulsed electronic fence detector is installed on the fence to protect the center, and the center is equipped with an alarm receiving host and the like.

The perimeter of the ground defense alarm system.

The front-end equipment is mainly an electronic fence. The electronic fence system is a kind of “tangible” alarm system, which gives people a sense of deterrence, which increases the psychological pressure of the intruder, thus organically combining the alarm system and the warning system. Get up, achieve the purpose of prevention and prevention . It has been widely used in the field of perimeter security in foreign countries. It can be used as a pre-deterrent, blocking and alarming at the time of the incident, and delaying the invasion time of the outside world. It has strong security and reliability. After installing the system, it is equivalent to forming a "tangible" electronic barrier on the top of the wall, increasing the height of the wall, making it impossible for outsiders to invade, and making people inside the wall unable to escape from the wall. The electronic pulse scans every wire of the electronic wall 60 times per minute, with 5-10 kV peaks per pulse, making it difficult for intruders to climb. In addition, if the system is disconnected, short-circuited or loses power, the system will issue an alarm signal. It can also be used in conjunction with any alarm system to improve the level of protection. The system can output two sets of alarm signals for the pulse host and the front end fence respectively, so that the user can check the cause of the alarm in time when the system alarms. The system design will make a reasonable division of the prevention area, as far as possible to accurately locate the alarm, and the prevention range of each area is controlled within the visual field of the human eye. There are no dead spots and no blind spots in the perimeter defense zone. (Intelligent perimeter security blocking alarm system includes front-end fence, pulse host, zone site linkage monitoring and on-site alarm and control center alarm handler)

1.1 main functions

Physical barrier: The conductive fence can be used to block the safety of the climbing structure - the wall (net) is loaded or unloaded

Holding a total height of 2.4 meters or more, the wire spacing is 10-20 cm, and the end is inclined 30 degrees to the outside, increasing the intruder's fear

Reason and difficulty in climbing.

Electric shock defense: When an intruder climbs or destroys a conductive fence, it can generate a pulse electric shock, using electric shock to induce pain and muscle

痉挛 Reflection, effective deterrence or forced termination of intrusion.

Detection alarm: Monitor the conductive fence for abnormal conditions such as electric shock, short circuit and open circuit and output an alarm signal.

System networking: equipped with alarm output, remote control and computer communication interface, supporting networking with other security systems

And linkage cameras and more.
